SUPERLATIVE PRESS PERFORMANCE

• Speed up to 46,000 IPH (with unit shaftless drive)
• Only Available with Unit Shaftless Design
• Three ink form roller design
• Robust construction - 35,000 lb (15,876 kilos) 4-high tower
• Outstanding Print Quality

Cutoff: 21” through 22.750” (533mm through 578mm)

Web Widths (cut-off dependent): 36" through 40" (914mm through 1016mm)

Outstanding Print Quality

• Three ink form rollers with three ink vibrators for high coverage inking capability
• Engineered specifically to maximize print results with third ink form roller design
• Large capacity ink fountains
• Ink form rollers swing out for easy plate-up access on both sides of the press

High-strength cast iron frames for outstanding stability and endurance

• Full bearer press design for enhanced dot reproduction and the ability to print fine screen work
• Bearing-in-a-bearing technology offers full cylinder support at high press speeds when using conventional narrow gapped blanket technology
• Ability to run 3-across formats up to 40" web widths

Highly Automated Controls

• State-of-the-art drives and controls provide optimum efficiency with minimal waste
• Unit shaftless drive system with integrated logistics for all auxiliary equipment

Innovative Design

• Drive side oil lubrication
• Plate cylinder design provides increased rigidity for outstanding print and registration control
• Quick “no tool” plate change design encourages versatility of products
